PFC V3 Slotted Replacement Rotor - Right - BMW E46 M3
Achieve precision braking upgrades for your BMW E46 M3 with the PFC V3 Direct Drive Replacement Rotor – Right Side (Part #322.28.0053.463). Designed for compatibility with existing PFC V3 Direct Drive hat assemblies, this two-piece floating rotor offers tool-free performance, superior thermal control, and lasting durability—perfect for performance enthusiasts and track-ready builds.
.%20Designed%20for%20compatibility%20with%20existing%20PFC%20V3%20Direct%20Dr...){kind=link}
Common Vehicle Fitments:
| BMW | E46 M3 | 2000-07 | Front |
- Part Number: 322.28.0053.463 — Right-side rotor for BMW E46 M3 front (use with V3 hat assembly)
- 2-Piece Floating Rotor Design — Allows thermal expansion while reducing warping and vibration
- High-Carbon Alloy with Copper & Molybdenum — Engineered for heat resistance and long-term durability
- Precision-Turned Vanes (ID & OD) — Facilitates ultimate cooling and operational balance
- Ultra-Tight Tolerances — Runout < 0.001″; Thickness variation < 0.0003″ for smooth braking response
- Streamlined Serviceability — Designed for quick, hat-compatible rotor swaps
- Track-Tested & Street-Savvy — Ideal for both spirited driving and sustained performance use
Performance Friction 322.28.0053.453 & 322.28.0053.463 Replacement Rotors only for the Performance Friction V3 Direct Drive system for the BMW E46 Front brakes. Includes Replacement Rotor only (Hat not included). Price is per rotor. The V3 design features an all new retention ring that holds the hat and disc together without the need for traditional nuts & bolts. The simplified design also helps save weight and makes rotor replacement a breeze. The 2-turn retaining ring is held in a groove in the hat that overlaps the rotor flanges, effectively locking the rotor to the hat.
- V3 style mounting hardware
- High Carbon Alloy with copper and molybdenum for high temperature strength and durability.
- Vanes turned OD and ID for balance to reduce thermal warping and vibration.
- Runout less than .001 inches, reducing Pulsation and Vibration.
- Thickness variation less than .0003 inches reduces Pulsation and Vibration.
- 47 or more vanes for superior thermal capacity.
- Aircraft quality heat treated for micro structure alignment and durability.
- Surface finish less than .7 microns.
- 100% measured and inspected to meet tolerance specifications.
2-piece rotors offer better cooling over a one-piece design. Performance Friction's full floating Direct Drive attachment system allows the brake disc to naturally expand/contract both radially and axially without being constrained by the hub. This helps eliminate rotor warping, vibrations and pulsations.
Note: Performance Friction Brake Pads are recommended for this set up. All other pads must be checked for proper rotor clearance at installation and periodically as they wear. Some brands of brake pads will fit at time of installation, but may contact the rotor-hat during use which can lead to brake failure.
